Integrity picture awning standard sizes. Integrity from marvin takes the values that made marvin a leader and applies them to a line of popular styles. Ultimate casement awning and picture uca ucanf 2 19972255 marvin architectural detail manual ver 2019 3 2019 06 24 unit features uawn uawnnf hardware. The marvin essential awning window offers clean lines with top hinged operation ideal for hard to reach areas or for access to fresh air even during a light rain. Because they open at the bottom awning windows naturally shed water so it may be possible to keep them open in wet weather.

Casement or awning windows and may be rotated 90 and used as a sidelight with casement awning or picture windows. With an exterior of ultrex a pultruded fiberglass material that outperforms and outlasts vinyl vinyl clad and roll form aluminum integrity windows and doors are built to perform under pressure and over time. Optional op o lock hardware only available with uawn requires a folding handle minimum frame om width is 28 711 minimum frame height is 15 1 8 384 maximum frame om width is 72 1829 maximum frame om height is 47 1 8 1197. Venting stationary custom size windows are available in 1 8 3 increments.

The marvin elevate collection is an ideal blend of remarkable design and superior strength bringing balance to your style and performance needs. Awning windows excel at bringing in a cool breeze and letting stagnant hot air flow out of a room. A top hinged alternative to a casement window the marvin elevate awning window is a convenient option for hard to reach areas like over a sink or counter or as a way to access fresh air even during a light rain. A dual point locking system is easy to engage from lever hardware at the sides of the window and style meets durability with a low maintenance fiberglass exterior and warm wood.

Designed for unprecedented performance and exceptional aesthetics we offer window options for every style of home in any climate. Patented fiberglass exteriors stand up to all elements outperforming and outlasting vinyl roll form aluminum and other fiberglass composites. Like casements awning window are energy efficient because the wind blowing on them can actually create a tighter seal. The essential awning window can be used on its own or combined with other casement picture or transom windows for maximum daylight and air flow.

Windows can also be custom sized to match standard sizes ending in a sixteenth of an inch. Our tools and documents resource center helps you find technical documents for all marvin window and door products. Strike the perfect balance of beauty and strength.
